Product Spotlight | EFFICIENCY AND TECHNOLOGY ON THE FARM
1500 & 1700 Series
Bale Accumulators
AE18
Built to handle hay turning, fluffing and merging in a single pass, the Fair Manufacturing 1500 and 1700 Series Hay Rakes are designed to help producers manage drying conditions and windrow formation during hay production.
Features:
• Available in 15-wheel( 1500 Series) and 17-wheel( 1700 Series) configurations with 60-inch rake wheels
• Three-in-one functionality allows operators to turn, fluff and merge hay windrows
• Centralized frame designed for maneuverability and tighter turning on end rows
• Up to 28-foot( 1500) or 31-foot( 1700) raking widths with adjustable windrow widths from 30 to 70 inches
• Weatherproof control panel operates with one tractor remote; dual spring wheel suspension designed for ground contouring and flotation
Fair Manufacturing, Inc. | fairmfg. com
AR2208 8-Wheel Action Rake
When small square bales start adding up, the Norden AE18 Bale Accumulator is built to group and arrange them into organized 18-bale packs for handling and transport.
Features:
• Handles bales from 32 to 40 inches in length
• Arranges bales in 18-bale groups, six wide by three long
• Twisted chute turns bales onto edge during loading
• Stainless steel deck designed for sliding in dirt and moisture conditions
• Gravity-driven gates and automatic rear gate manage bale release and reset for the next group
Norden Mfg | nordenmfg. com
AC 4108
Designed to help shape clean windrows while maintaining crop flow through the field, the H & S AR2208 8-Wheel Action Rake combines adjustable raking settings with a high-clearance frame for hay operations.
Features:
• Eight 60-inch rake wheels with greaseable tapered bearings
• High-clearance frame with wide wheel stance for transport stability
• Adjustable rake wheel pressure for ground contouring
• Raking width from about 16 feet, 6 inches to 17 feet, 8 inches
• Adjustable windrow width and single-remote hydraulic operation
H & S Manufacturing Company, Inc. | www. hsmfgco. com
During hay season, when timing matters, the PhiBer AC 4108 Accumulator organizes bales in the field and releases them in controlled groups to streamline pickup and hauling.
Features:
• Fully automatic operation with up to three eject patterns plus hold mode
• Handles bales from 4.25 to 9 feet in length
• Designed for dry hay and baleage applications
• Powered by tractor hydraulics and compatible with open center, closed center and load-sensing systems
• Accommodates 3- to 4-foot-wide bales with a 6,000-pound capacity and optional scale system
PhiBer Manufacturing Inc. | phiber. ca
