BATES STEEL MULE
ANTIQUE TRACTORS
BATES STEEL MULE
ANTIQUE TRACTORS
ALL STEEL OIL
YEARS MFRD.......................... 1916 ENGINE................................ BATES CYLINDERS................................... 2 BORE AND STROKE............. 7X8 1 / 2 RPM......................................... 500 FUEL.............................. KEROSENE MAIN FUEL TANK CAP................. 15 COOLING CAPACITY.................... 10 DRAWBAR HP............................. 20 BELT PTO HP.............................. 30 WEIGHT......................... 8,000 LBS. MSRP..................................$ 1,650
ALL STEEL OIL 15-25
YEARS MFRD................. 1919-1921 ENGINE................. BATES VERTICAL CYLINDERS................................... 4 BORE AND STROKE....... 4 1 / 2X5 3 / 4 RPM......................................... 800 WEIGHT......................... 4,000 LBS.
MODEL D 15-22
YEARS MFRD................. 1912-1920 ENGINE..................... ERD VERTICAL............................... VALVE IN HEAD CYLINDERS................................... 4 BORE AND STROKE......... 4.50X6.00 RPM...................................... 1,100 FUEL.............................. KEROSENE CARBURETOR.... BENNETT MODEL J DRAWBAR HP........................ 20.66 BELT PTO HP.............................. 25 WEIGHT......................... 4,900 LBS. NUM OF GEARS......................... 2 / 1
MODEL H 15-25
YEARS MFRD................. 1921-1925 ENGINE.... MIDWEST VALVE IN HEAD CYLINDERS................................... 4 BORE AND STROKE....... 4 1 / 8X5 1 / 4 RPM......................................... 580 WEIGHT......................... 4,000 LBS.
15-22 HALFTRACK
YEARS MFRD.......................... 1920 ENGINE............ MIDWEST VERTICAL.............................. VALVE IN HEAD CYLINDERS................................... 4 BORE AND STROKE....... 4.125X5.25 RPM...................................... 1,100 FUEL........................................ GAS CARBURETOR.... BENNETT MODEL J BELT PTO HP......................... 29.78 WEIGHT......................... 4,600 LBS. NUM OF GEARS......................... 2 / 1
ANTIQUE CRAWLERS
INDUSTRIAL 20-25
YEARS MFRD................. 1924-1926 ENGINE...... BEAVER-VALVE IN HEAD CYLINDERS................................... 4 BORE AND STROKE............. 4 1 / 4X6 RPM......................................... 850 WEIGHT......................... 6,500 LBS. TREAD WIDTH............................. 10 TRACK LENGTH.......................... 64
INDUSTRIAL 25-35 MODEL G
YEARS MFRD................. 1921-1927 ENGINE............ MIDWEST-VERTICAL CYLINDERS................................... 4 BORE AND STROKE............. 4 1 / 2X6 RPM......................................... 850 CARBURETOR.. BENNETT 1 1 / 2 INCH WEIGHT......................... 6,500 LBS. NUM OF GEARS......................... 3 / 2
INDUSTRIAL 30-40
YEARS MFRD................. 1924-1926 ENGINE............ WAUKESHA-L HEAD CYLINDERS................................... 4 BORE AND STROKE............. 5X6 1 / 4 RPM......................................... 850 CARBURETOR................. KINGSTON.................................... 1 1 / 2 INCH WEIGHT......................... 9,500 LBS. TREAD WIDTH............................. 12 TRACK LENGTH.......................... 84
18-25 STEEL MULE MODEL F
YEARS MFRD................. 1921-1927 ENGINE.... MIDWEST-VALVE IN HEAD CYLINDERS................................... 4 BORE AND STROKE....... 4 1 / 8X5 1 / 4 RPM......................................... 850 CARBURETOR................... BENNETT WEIGHT......................... 4,850 LBS. NUM OF GEARS......................... 4 / 2 TREAD WIDTH............................. 10 TRACK LENGTH.......................... 58
35
YEARS MFRD.......................... 1931 ENGINE............ WAUKESHA L-HEAD CYLINDERS................................... 6 BORE AND STROKE......... 4.25X4.75 RPM...................................... 1,500 FUEL........................................ GAS CARBURETOR.......... SCHEBLER HDX DRAWBAR HP........................ 43.73 BELT PTO HP......................... 52.58 WEIGHT....................... 11,218 LBS.
45
YEARS MFRD................. 1931-1931 ENGINE............ WAUKESHA L-HEAD CYLINDERS................................... 6 BORE AND STROKE..... 4.625X5.125 RPM...................................... 1,500 FUEL........................................ GAS CARBURETOR.......... SCHEBLER HDX DRAWBAR HP........................ 66.53 WEIGHT....................... 13,509 LBS.
