WALLIS ANTIQUE TRACTORS
BEAR
YEARS MFRD................. 1912-1913 FACTORY................. CLEVELAND, OH QTY MADE................................. 10 ENGINE............................... WALLIS CYLINDERS................................... 4 BORE AND STROKE........... 7.5X8.00 RPM......................................... 650 CID........................................ 1590 MAIN FUEL TANK CAP................. 60 DRAWBAR HP............................. 30 BELT PTO HP.............................. 50 WEIGHT....................... 16,000 LBS. NUM OF GEARS............................ 3
SERIAL NUMBERS ON TOP OF TRANSMISSION CASE TO REAR OF SHIFT LEVER YEAR........................ BEGINNING NO 1912................................ 201-INA 1913................................ INA-210
CERTIFIED 12-20
YEARS MFRD................. 1929-1935 FACTORY........................ RACINE, WI ENGINE................... OWN VERTICAL CYLINDERS................................... 4 BORE AND STROKE....... 3.875X5.25 RPM...................................... 1,000 FUEL........................................ GAS MAIN FUEL TANK CAP................. 15 CARBURETOR................. KINGSTON COOLING CAPACITY...................... 5 DRAWBAR HP........................ 12.34 BELT PTO HP......................... 20.32 WEIGHT......................... 3,432 LBS. NUM OF GEARS......................... 3 / 1 MSRP.....................................$ 875
CERTIFIED 20-30
YEARS MFRD................. 1927-1932 FACTORY........................ RACINE, WI ENGINE............................ VERTICAL CYLINDERS................................... 4 BORE AND STROKE....... 4.375X5.75 RPM...................................... 1,050 FUEL........................................ GAS MAIN FUEL TANK CAP................. 20 CARBURETOR................. KINGSTON COOLING CAPACITY................. 6.75 DRAWBAR HP.......................... 19.8 BELT PTO HP......................... 30.24 WEIGHT......................... 4,381 LBS. NUM OF GEARS......................... 2 / 1 MSRP..................................$ 1,295
CUB 26-52
YEARS MFRD................. 1914-1917 FACTORY........................ RACINE, WI ENGINE............................ VERTICAL BORE AND STROKE................... 6X7 RPM......................................... 650 FUEL............. KEROSENE / GASOLINE CARBURETOR................... BENNETT
CUB JUNIOR 13-25
YEARS MFRD.......................... 1918 ENGINE............................... WALLIS CYLINDERS................................... 4 BORE AND STROKE....... 4 1 / 4X5 3 / 4 FUEL.............................. KEROSENE WEIGHT......................... 3,250 LBS.
CUB JUNIOR 15-25
YEARS MFRD................. 1918-1922 QTY MADE............................ 8,715 ENGINE............................. J. I. CASE CYLINDERS................................... 4 BORE AND STROKE......... 4.25X5.75 RPM......................................... 900 CID....................................... 326.3 FUEL............. KEROSENE / GASOLINE MAIN FUEL TANK CAP................. 20 AUX. FUEL TANK CAP................. 1.6 CARBURETOR.......... BENNETT H & J AIR CLEANER.................... BENNETT COOLING CAPACITY...................... 6 DRAWBAR HP............................. 15 BELT PTO HP.............................. 25 WEIGHT......................... 2,560 LBS. NUM OF GEARS......................... 2 / 1
CUB JUNIOR 15-30
YEARS MFRD................. 1917-1919 FACTORY........................ RACINE, WI ENGINE............................ VERTICAL CYLINDERS................................... 4 BORE AND STROKE....... 4 1 / 4X5 3 / 4 RPM......................................... 900 FUEL............. KEROSENE / GASOLINE
CUB JUNIOR MODEL J
YEARS MFRD................. 1915-1916 QTY MADE............................ 3,505 ENGINE............................ VERTICAL............................. VALVE-IN-HEAD CYLINDERS................................... 4 BORE AND STROKE......... 4.25X5.75 RPM......................................... 875 CID.......................................... 366 FUEL........................................ GAS MAIN FUEL TANK CAP................. 20 CARBURETOR................... BENNETT COOLING CAPACITY...................... 9 DRAWBAR HP............................. 15 BELT PTO HP.............................. 25 WEIGHT......................... 3,345 LBS. NUM OF GEARS......................... 2 / 1
SERIAL NUMBERS YEAR........................ BEGINNING NO 1915............................ 10001-INA 1916............................ INA-13505
CUB MODEL K
YEARS MFRD................. 1916-1922 FACTORY........................ RACINE, WI ENGINE............... WALLIS VERTICAL CYLINDERS................................... 4 BORE AND STROKE......... 4.25X5.75 RPM......................................... 900 FUEL........................................ GAS MAIN FUEL TANK CAP................. 20 CARBURETOR................... BENNETT COOLING CAPACITY...................... 6 DRAWBAR HP............................. 15 BELT PTO HP.............................. 25 WEIGHT......................... 3,870 LBS.
SERIAL NUMBERS YEAR........................ BEGINNING NO 1916............................ 14001-INA 1917........................................ INA 1918........................................ INA 1919........................................ INA 1920........................................ INA 1921........................................ INA 1922............................ INA-23156
WALLIS
ANTIQUE TRACTORS
CUB OPEN GEARS
YEARS MFRD................. 1913-1917 CYLINDERS................................... 4 BORE AND STROKE......... 6.00X7.00 RPM......................................... 650 FUEL................................ ALL FUEL MAIN FUEL TANK CAP................. 30 WEIGHT......................... 8,500 LBS. NUM OF GEARS......................... 2 / 1
K3
YEARS MFRD................. 1916-1922 ENGINE............... WALLIS VERTICAL BORE AND STROKE......... 4.25X5.75 RPM......................................... 900 FUEL........................................ GAS MAIN FUEL TANK CAP................. 20 CARBURETOR................... BENNETT COOLING CAPACITY...................... 6 DRAWBAR HP............................. 15 BELT PTO HP.............................. 25 WEIGHT......................... 3,870 LBS.
K 15-25
YEARS MFRD................. 1919-1923 FACTORY........................ RACINE, WI ENGINE............................... WALLIS CYLINDERS................................... 4 BORE AND STROKE......... 4.25X5.75 RPM......................................... 900 CID....................................... 326.3 FUEL........................................ GAS DRAWBAR HP........................ 18.58 BELT PTO HP......................... 29.87 WEIGHT......................... 3,500 LBS. NUM OF GEARS......................... 2 / 1
K 15-25
YEARS MFRD................. 1919-1923 ENGINE............................... WALLIS CYLINDERS................................... 4 BORE AND STROKE......... 4.25X5.75 RPM......................................... 900 CID....................................... 326.3 FUEL........................................ GAS DRAWBAR HP........................ 18.58 BELT PTO HP......................... 29.87 WEIGHT......................... 3,500 LBS. NUM OF GEARS......................... 2 / 1
800-247-2000 • Hot Line Antique Tractor Guide ® 2026 475
