GEHL t e l e h a n d l e r s
2017......... $ 54,810......... $ 41,057 2018......... $ 56,158......... $ 46,833 2019......... $ 57,597......... $ 49,706 2020......... $ 59,682......... $ 52,256 2021......... $ 62,069......... $ 54,836 2022......... $ 64,456......... $ 57,417 2023......... $ 65,139......... $ 58,622 2024......... $ 65,985......... $ 59,911
RS6-34
YEARS MFRD....... 2004- 2019 ENGINE.............. JD 4045T ENGINE HP.............. 99.00 TRANSMISSION......... 3SP PS LIFT CAPACITY........ 6,000 LBS. CAP AT MAX LIFT...... 4,000 LBS. CAP AT MAX REACH..... 900 LBS. LIFT HEIGHT.............. 34’ 3” MAX REACH.............. 23’ 3” WEIGHT............ 15,100 LBS.
RETAIL PRICING YEAR HIGH LOW 2005......... $ 36,163......... $ 27,122 2006......... $ 40,793......... $ 30,607 2007......... $ 44,040......... $ 33,027 2008......... $ 46,246......... $ 34,668 2009......... $ 47,471......... $ 35,820 2010......... $ 52,357......... $ 39,263 2011......... $ 54,821......... $ 41,112 2012......... $ 61,790......... $ 46,304 2013......... $ 68,381......... $ 51,280 2014......... $ 69,815......... $ 52,365 2015......... $ 71,284......... $ 53,462 2016......... $ 72,779......... $ 54,576 2017......... $ 74,525......... $ 56,229 2018......... $ 76,357......... $ 59,094 2019......... $ 78,131......... $ 62,004
RS6-34 GEN 2
YEARS MFRD....... 2016- 2024
2016-2019 ENGINE...... DEUTZ TD3.6 TIER 4 ENGINE HP.............. 74.00 TRANSMISSION........ 3SPD PS LIFT CAPACITY........ 6,000 LBS. CAP AT MAX LIFT...... 4,000 LBS. CAP AT MAX REACH..... 900 LBS. LIFT HEIGHT.............. 34’ 3” MAX REACH.............. 23’ 3” WEIGHT............ 15,100 LBS.
GEN 3 2018-2023 ENGINE...... DEUTZ TD3.6 TIER 4 ENGINE HP.............. 74.00 TRANSMISSION........ 3SPD PS LIFT CAPACITY........ 6,000 LBS. CAP AT MAX LIFT...... 4,000 LBS. CAP AT MAX REACH..... 900 LBS. LIFT HEIGHT.............. 34’ 3” MAX REACH.............. 23’ 3” WEIGHT............ 15,100 LBS.
RS6-34 MARK 74
YEARS MFRD....... 2018- 2020 ENGINE.. CUMMINS QSF3.8 TIER 4 ENGINE HP.............. 74.00 TRANSMISSION.... DANA 4SPD PS LIFT CAPACITY........ 6,600 LBS. CAP AT MAX LIFT...... 6,600 LBS. CAP AT MAX REACH.... 1,000 LBS. LIFT HEIGHT............... 42’ MAX REACH.............. 28’ 3”
RS6-42
YEARS MFRD....... 2004- 2018 ENGINE.............. JD 4045T ENGINE HP.............. 99.00 TRANSMISSION......... 3SP PS LIFT CAPACITY........ 6,600 LBS. CAP AT MAX LIFT...... 6,600 LBS. CAP AT MAX REACH.... 1,000 LBS. LIFT HEIGHT............... 42’ MAX REACH.............. 28’ 3” WEIGHT............ 22,000 LBS.
RETAIL PRICING YEAR HIGH LOW 2004......... $ 36,678......... $ 27,515 2005......... $ 40,732......... $ 30,552 2006......... $ 43,225......... $ 32,420 2007......... $ 49,461......... $ 37,087 2008......... $ 51,189......... $ 38,392 2009......... $ 53,749......... $ 40,304 2010......... $ 56,426......... $ 42,325 2011......... $ 57,958......... $ 43,458 2012......... $ 59,842......... $ 48,159 2013......... $ 60,449......... $ 49,058 2014......... $ 64,283......... $ 50,620 2015......... $ 66,962......... $ 51,725 2016......... $ 68,055......... $ 53,192 2017......... $ 70,338......... $ 55,992 2018......... $ 73,730......... $ 59,057
RS6-42 GEN 2
YEARS MFRD....... 2014- 2022
2014-2018 ENGINE.. CUMMINS QSF3.8 TIER 4 ENGINE HP............. 120.00 TRANSMISSION.... DANA 3SPD PS LIFT CAPACITY........ 6,600 LBS. CAP AT MAX LIFT...... 6,600 LBS. CAP AT MAX REACH.... 1,000 LBS. LIFT HEIGHT............... 42’ MAX REACH.............. 28’ 3” WEIGHT............ 22,000 LBS. GEN 3 2018-2022 ENGINE.. CUMMINS QSF3.8 TIER 4 ENGINE HP............. 120.00 TRANSMISSION.... DANA 3SPD PS LIFT CAPACITY........ 6,600 LBS. CAP AT MAX LIFT...... 6,600 LBS. CAP AT MAX REACH.... 1,000 LBS.
LIFT HEIGHT............... 42’ MAX REACH.............. 28’ 3” WEIGHT............ 22,000 LBS.
TH6-42
YEARS MFRD....... 2023- 2024 ENGINE... DEUTZ TD3.6 L4 TIER 4 ENGINE HP.............. 74.00 TRANSMISSION........ 5SPD PS LIFT CAPACITY........ 6,000 LBS. LIFT HEIGHT.............. 42’ 6” MAX REACH.............. 28’ 6” WEIGHT............ 22,851 LBS.
WINDROWERS
DC2345 CONVENTIONAL
YEARS MFRD....... 2004- 2006 TRANSMISSION.... 540 / 1000 PTO HEAD SIZE................ 9’ 2” WEIGHT............. 3,825 LBS.
DC2365 CONVENTIONAL
YEARS MFRD....... 2004- 2006 TRANSMISSION.... 540 / 1000 PTO HEAD SIZE............... 10’ 3” WEIGHT............. 4,100 LBS.
DC2412 SWING FRAME
YEARS MFRD....... 2004- 2006
11’ 7” TRANSMISSION....... 1000 PTO HEAD SIZE............... 11’ 7” WEIGHT............. 5,100 LBS.
15’ 1” TRANSMISSION....... 1000 PTO HEAD SIZE............... 15’ 1” WEIGHT............. 7,500 LBS.
DC2415
YEARS MFRD....... 2004- 2005 TRANSMISSION....... 1000 PTO HEAD SIZE................ 15’ WEIGHT............. 7,500 LBS.
DC2418 SWING FRAME
YEARS MFRD....... 2004- 2006 TRANSMISSION....... 1000 PTO HEAD SIZE............... 17’ 9” WEIGHT............. 8,000 LBS.
2170
YEARS MFRD....... 1987- 1990 TRANSMISSION........ 540 PTO HEAD SIZE................. 9’ HEAD OPTION............ SICKLE
2512 IMPELLER
YEARS MFRD....... 2005- 2006 TRANSMISSION....... 1000 PTO HEAD SIZE.............. 11’ 10” WEIGHT............. 4,950 LBS.
GENIE
TELEHANDLERS
GTH-636
YEARS MFRD....... 2006- 2024
4WD ENGINE........ DEUTZ TD 2.9 L4 ENGINE HP.............. 99.00 TRANSMISSION............. PS LIFT CAPACITY........ 6,000 LBS. CAP AT MAX LIFT...... 5,000 LBS. CAP AT MAX REACH.... 1,500 LBS. LIFT HEIGHT............... 36’ MAX REACH............. 21’ 11” WEIGHT............ 17,600 LBS.
GTH-5519
YEARS MFRD....... 2006- 2024
ENG: DEUTZ TIER III DIESEL ENGINE..... DEUTZ TIER III DIESEL ENGINE HP.............. 68.00 TRANSMISSION.......... HYDRO LIFT CAPACITY........ 5,500 LBS. CAP AT MAX LIFT...... 4,400 LBS. CAP AT MAX REACH.... 1,900 LBS. LIFT HEIGHT............... 19’ MAX REACH............... 11’ WEIGHT............ 10,360 LBS.
ENG: PERKINS TIER IV DIESEL ENGINE... PERKINS TIER IV DIESEL ENGINE HP............. 148.00 TRANSMISSION.......... HYDRO LIFT CAPACITY........ 5,500 LBS. CAP AT MAX LIFT...... 4,400 LBS. CAP AT MAX REACH.... 1,900 LBS. LIFT HEIGHT............... 19’ MAX REACH............... 11’ WEIGHT............ 10,360 LBS.
