LAUSON ANTIQUE TRACTORS
LAUSON 65
YEARS MFRD................. 1929-1937 ENGINE........................ WISCONSIN CYLINDERS................................... 6 BORE AND STROKE............. 3 7 / 8X5 DRAWBAR HP............................. 22 BELT PTO HP.............................. 35
12-25
YEARS MFRD................. 1922-1925 ENGINE............ MIDWEST VERTICAL............................. VALVE-IN-HEAD CYLINDERS................................... 4 BORE AND STROKE....... 4.125X5.25 RPM...................................... 1,200 FUEL........................................ GAS CARBURETOR............... KINGSTON L DRAWBAR HP........................ 20.91 WEIGHT......................... 4,500 LBS. NUM OF GEARS......................... 2 / 1
15-25
YEARS MFRD................. 1916-1919 ENGINE.................... ERD VERTICAL.............................. VALVE-IN-HEAD CYLINDERS................................... 4 BORE AND STROKE................... 4X6 RPM......................................... 950 CARBURETOR................. KINGSTON DRAWBAR HP............................. 15 BELT PTO HP.............................. 25 WEIGHT......................... 5,000 LBS.
15-30 ROAD TRACTOR
YEARS MFRD................. 1920-1921 ENGINE............... BEAVER VERTICAL.............................. VALVE-IN-HEAD CYLINDERS................................... 4 BORE AND STROKE......... 4.75X6.00 RPM......................................... 950 FUEL.............................. KEROSENE CARBURETOR............... KINGSTON L DRAWBAR HP........................ 17.68 WEIGHT......................... 6,500 LBS. NUM OF GEARS......................... 2 / 1
16-32
YEARS MFRD................. 1920-1921 ENGINE........ BEAVER VALVE-I-HEAD CYLINDERS................................... 4 BORE AND STROKE......... 4.50X6.00 RPM...................................... 1,100 FUEL........................................ GAS CARBURETOR........... KINGSTON L-3 AIR CLEANER.............. TACO WATER DRAWBAR HP.......................... 28.9 WEIGHT......................... 5,890 LBS. NUM OF GEARS......................... 2 / 1
20-35 S-10
YEARS MFRD................. 1926-1930
20-35 S-12
YEARS MFRD.......................... 1916 ENGINE.................. LEROI VERTICAL.......................................... I-HEAD CYLINDERS................................... 4 BORE AND STROKE......... 4.50X6.00 RPM...................................... 1,100 FUEL........................................ GAS CARBURETOR........... TILLOTSON R2 DRAWBAR HP............................. 20 BELT PTO HP.............................. 35 WEIGHT......................... 7,300 LBS. NUM OF GEARS......................... 2 / 1
20-40
YEARS MFRD................. 1926-1930 ENGINE............... BEAVER VERTICAL.............................. VALVE-IN-HEAD CYLINDERS................................... 4 BORE AND STROKE......... 4.75X6.00 RPM...................................... 1,040 CARBURETOR........... KINGSTON L-3 AIR CLEANER.......................... TACO DRAWBAR HP........................ 32.02 WEIGHT......................... 7,914 LBS. NUM OF GEARS......................... 2 / 1
20-40 THRESHERMAN
YEARS MFRD................. 1926-1930 BELT PTO HP.............................. 50 WEIGHT......................... 8,650 LBS.
25-45 THRESHERMAN
YEARS MFRD................. 1929-1937 ENGINE................................. LEROI CYLINDERS................................... 6 BORE AND STROKE............. 4 1 / 2X6 WEIGHT......................... 9,060 LBS.
LAUSON
ANTIQUE TRACTORS
800-247-2000 • Hot Line Antique Tractor Guide ® 2026 325
